HDMI Video Wall Controller 2 x 2

Product Features:
(1)The finished product is a pure hardware structure with three basic splicing modes. It can also be used with a splitter
to connect multiple screen images in series to meet your application needs and suit more scenes.
(2) The new splicer supports 1x2, 2x2, 1x4 composition into a large screen, independent audio output, can be connected
to the audio, headphones; no computer control, convenient and stable stitching.
(3) A high-definition image signal is divided into 4 blocks and then assigned to 4 display screens; 4 display screens
are combined into a large screen in 2x2 mode.
(4) A high-definition image signal is divided into 4 blocks and assigned to 4 display screens; 4 display screens
are combined into a large screen in 1x4 mode.
(5)Support 180° rotate function,it only fit for 2x2 mode, the first row of 2 display unit can rotate 180 degree.
Product parameters:
(1) Support 1 channel DVI or HDMI input
(2) Input support HDMI1.4, HDCP1.4
(3) Support 4 channels of HDMI output, 3.5 mm audio output
(4) Input resolution: 1920x1080P/60HZ, 3840x2160P 30HZ [ "1080P 2X2", do not support 4K30 input ]
(5) Output resolution: 1920x1080P 60HZ
(6) Input format: RGB / YUV 24bit; Output format: RGB444 24bit
(7) Easy to operate, plug and play
(8)DC 12V / 2A power adapter
